Product Details:
Payment & Shipping Terms:
|
| Product: | 200 * 6 * 5950mm Middle Groove Waterproof Wall Panels Decorative Ceiling | Size: | 200 * 6 * 5950mm |
|---|---|---|---|
| Shape: | Middle Groove Board | Weight: | 2.5kg Per Piece |
| Fire Rating: | B1 Level | Packing: | 10pcs In Each PE Film Bag |
| High Light: | plastic bathroom shower panels,waterproof wall board |
||
200 * 6 * 5950mm Middle Groove Waterproof Wall Panels Decorative Ceiling
It is 8 inches wide and available in custom lengths and an assortment of colors. Can be used in a variety of applications, such as wall for kitchens and baths. Great as a ceiling for your porch (without direct sunlight) or other rooms that you would like to have a crisp, clean, professional look.
1) PVC panel is an new system of light weight construction for ceiling and wall, its assembly system always offer elegance and different finishes
2) PVC panels are made from a robust plastic material called PVC.They are attractive, last for years and require almost no maintenance.
3) PVC panels offer the home or business owner a cost efficient alternative to regular crinoline ceilings.
4) PVC panels offer excellent insulation, keeping you warm in the winter and cool during the summer.
5) PVC panels are available in a huge variety of colours and designs offering a classy ceiling for a fraction of the cost of normal ceilings.
6) PVC panels are available in a wide variety of colours and designs
PVC Panel Introduction:
Width: 20cm (8 inch)
Length: 5.8m (19 feet) or 5.95m (19.5 feet)
Thickness: 6mm
| Finish | Size | Weight | Fire Classification | Packaging |
| Printing | 200×6mm | 2.1kg/m2 | Class B1 |
10pcs/pack 5.8m length =11.6sqm/bag |
PVC Panel Quality Testing:
| No. | Test Items | Technical Requirements | Detection Result | Single Judge | |
| 1 | Appearance | Fulfill | Qualified | ||
| 2 | Flexibility mm/m | <1.5mm/m | 0.48 | Qualified | |
| 3 | Thickness mm | Faceplate | >0.4 | 0.4 | Qualified |
| Base plate | >0.3 | 0.32 | |||
| 4 | Heating Rate % | <6.0 | 0.6 | Qualified | |
| 5 | Heated State | No bubble, craze or spot | Fulfill | Qualified | |
| 6 | Resistance of acetone | No defects | Fulfill | Qualified | |
| 7 | Dart drop impact | 0.25kg/0.5m,10 times, Pass when keep unbroken above 6 times | pass | Qualified | |
| 8 | Size Variation in High/Low Temperature | ±0.6% | -0.16 | Qualified | |
| 9 | Nail resistance | no visible cracks | Indehiscent | Qualified | |
PVC Panel Installation Procedure:
(1) Preparing all the necessary tools
(2) Measuring the size of panel you need to cut
(3) Cutting the panel by blade or jigsaw
(4) Fixing the kill
(5) Install the corner or jointer
(6) Install the panel into the corner
(7) Fixing the panel by staple nail gun on the keel
(8) Insert the second panel completely into the groove before stapling (nailing or screwing) into the lip. Proceed the same way with the next panels.
Why Choose Our PVC Panel?
|
* We are specialized in researching, developing, producing and sales of high quality PVC panel, PVC ceiling, PVC wall panel and other decorative panels as well as PVC profiles.
|
|
* Our products have long time working life, endurable 25years.
|
|
* Factory capacity: 200,000 square meters per month, 7 producing lines
|
|
* OEM Service Offered Design Service Offered Buyer Label Offered. Accept the new design developing.
|
|
* Our pvc ceiling panels are sold to worldwide and sale well in Middle East, South America, Europe, South Asia and Africa.
|
|
* We provide free samples |
PVC Panel Loading:
| SPECIFICATION | QUANTITY (SQM) | ||
| width | thickness | 20GP | 40HQ |
|
20cm
|
6.0mm | 4245 | 10350 |
| 7.0mm | 3650 | 8865 | |
| 7.5mm | 3390 | 8330 | |
| 8mm | 3190 | 7735 | |
| 8.5mm | 3016 | 7134 | |
